Wrapper gasket, Bottom burner box assembly – ADC AD-360X2 User Manual
Page 31
29
Telephone: (508) 678-9000
Fax: (508) 678-9447
Bottom Burner Box Assembly
Illus. No.
Part No.
Qty.
Description
1
141138
1
Two Port Burner Manifold
2
141137
2
Stainless Steel Burner Tube
3
128927
1
1/2 24 VAC (natural gas) Gas Valve
4
143118
1
1/2 x 1/2 x 60 Stainless Steel Flex Hose
5
354146
2
Bottom Burner Baffle
6
128915
1
Ignition with Flame Probe
7
801048
1
Direct Spark Ignition (DSI) Johnson Control
8
354162
1
Direct Spark Ignition (DSI) Module Mounting Panel
9
142506
1
1/2 x 1/2 Street Elbow
10
318700
1
Small Burner Tube Bracket
11
130400
1
Temperature Sensor
12
128919
1
36 Ignition Cable
13
354170
1
Burner Tube Hood
14
354261
1
Flexible Gas Line Bracket
15
354100
1
Manifold Support
16
140844
2
Burner Orifice
17
354049
1
Gas Valve Mounting Bracket
18
150512
2
1/4-20 x 1/2" Hex Head Machine Bolt
19
121300
1
Open/Closed Bushing
20
121400
1
7/8 Universal Bushing
21
150299
2
#10 x 1 Hex Washer TEK Screw
22
153562
2
#6-32 x 3/4 Black Self-Clinching Stud
23
152013
2
#6-32 Hex Nut
24
150309
29
#10-16 x 1/2 Hex Head TEK Crimptite Screw
25
153007
2
1/4 Split Lock Washer
26
152002
2
1/4-20 Hex Nut
27
120910
1
Green Ground Screw
28
153018
4
1/4 Flat Washer
29
860073
1
Phase 7 Burner Box
