Page 17
15
Telephone: (508) 678-9000
Fax: (508) 678-9447
Illus. No.
Part No.
Qty.
Description
1
154210
40
5/32 x 3/16 Pop Rivet
2
354217
1
Spacer Plate
3
153048
1
Inner Friction Teflon
®
Pad
4
116332
1
94 x 2-1/2 x 1/8 Felt Collar
5
882765
1
One Arm Basket (tumbler) Support Assembly
(includes illus. nos. 2, 3, and 5)
6
882766
1
Basket (tumbler) Assembly For One Arm Basket (tumbler) Support
(includes illus. nos. 1, 4, and 9)
882990
1
One Arm Basket (tumbler) and Support Assembly Complete
(includes illus. nos. 1 through 7 and 9)
7
154210
6
5/32 x 3/16 Pop Rivet
8
100191
1
12 Rib 105 Long (J) High Temperature Belt
9
115907
1
Inner Ring Felt Collar
401010
1
#847 Adhesive For Felt Collar (5 oz. tube)
Basket (Tumbler)/Support Assemblies
