Main Door Steel Assembly
Illus. No.
Part No.
Qty.
Description
1
881150
1
Black Main Door Assembly Complete
(includes illus. nos. 1, 2, and 8 through 15)
881207
1
Stainless Steel Main Door Assembly Complete
(includes illus. nos. 1, 2, and 8 through 15)
2
102354
1
Door Gasket
170730
1
Clear Glass Adhesive (10.3 oz. cartridge)
170731
Black Glass Adhesive (10.3 oz. cartridge)
3
881152
1
Black Top Hinge Block Assembly
(includes illus. nos. 3 and 4)
881208
1
Stainless Steel Top Hinge Block Assembly
4
150445
2
1/4-20 x 3/4 Black Cap Head Setscrew
5
153031
1
1/4 Nylon Washer
6
881151
1
Black Bottom Hinge Block Assembly
(includes illus. nos. 5, 6, and 7)
881209
1
Stainless Steel Bottom Hinge Block Assembly
7
150445
2
1/4-20 x 3/4 Black Cap Head Setscrew
150443
2
1/4-20 x 3/4 Stainless Steel Cap Head Setscrew
8
150683
3
1/4-20 x 5/8 Black Carriage Bolt
150682
3
1/4-20 x 5/8 Stainless Steel Carriage Bolt
(for models with stainless steel doors)
9
152014
3
1/4-20 Free Spin Wash Nut
10
151010
1
#10-32 Black Hex Acorn Nut
151009
1
#10-32 Stainless Steel Hex Acorn Nut
11
150120
1
Door Latch Screw
12
150683
3
1/4-20 x 5/8 Black Carriage Bolt
150682
3
1/4-20 x 5/8 Stainless Steel Carriage Bolt
(for models with stainless steel doors)
13
152014
3
1/4-20 Free Spin Wash Nut
14
881210
1
Black Main Door Handle ONLY
170333
1
Stainless Steel Main Handle ONLY
15
102211
1
Door Glass
