ADE-15/ADE-25 Transformer Usage Listing for Electric Dryers
ADE-15
ADE-25
KW VOLTAGE PHASE WIRE
STEP DOWN
TRANSFORMER PART NO.
CONTROL VOLTAGE
TRANSFORMER PART NO.
15 208 3ø 3 or 4 ------ 141403
18 460/480 3ш 3 132053 141403
12 208 3ш 3 ------ 141403
18 208 3ш 3 ------ 132070
12 240 3ш 3 ------ 141403
18 240 3ш 3 ------ 141403
12 380 3ш 4 ------ 132082
15 380 3ш 4 ------ 132082
11 400 3ш 4 ------ 132082
15 400 3ш 4 ------ 132082
18 416 3ш 4 ------ 132082
15 208 1ш 2 ------ 132063
18 208 1ш 2 ------ 132063
12 240 1ш 2 ------ 132070
KW VOLTAGE PHASE WIRE
STEP DOWN
TRANSFORMER PART NO.
(for 3 wire, 380-480 VAC systems)
CONTROL VOLTAGE
TRANSFORMER PART NO.
25 380 3ø 3 or 4 132059 132082
24 208 3ø 3 or 4 ------ 132063
24 230 3ш 3 ------ 132063
24 416 3ш 3 or 4 132062 132082
24 460/480 3ø 3 or 4 132053 141403
20 208 1ш 2 ------ 132063
20 230 1ш 2 ------ 132072
20 380 3ш 3 or 4 132059 132082
