ADG-15/ADG-25 Direct Spark Ignition (DSI) Burner Assembly
For Models Mfd. prior to May 20, 2000
Illus. No. Part No. Qty. Description
1 318030 1 Direct Spark Ignition (DSI) Burner Shield
2 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
3 150309 2 #10-16 x 1/2” Hex Head TEK Crimptite Screw
4 880134 1 Ignitor/Flame-Probe Kit Assembly
(includes illus. nos. 4 and 5)
5 880330 1 High Voltage (HV) Wire Connector Assembly
6 150103 2 #8-32 x 1/2” Pan Head Machine Screw
7 153000 2 #8 Steel Burr
8 151001 2 #8-32 Pal Nut
9 141104 2 Small Tube Burner ONLY
10 -------- 2 Burner Orifice
(refer to DSI Burner Orifice Listing on page 65)
11 141230 1 1/2” Direct Spark Ignition (DSI) Manifold (2-port)
12 318700 1 Pipe Bracket (bent)
13 150300 2 #10-16 x 1/2” Hex Washer TEK Screw
14 128927 1 1/2” 24 VAC Redundant Gas Valve (natural gas)
880960 1 1/2” 24 VAC Liquid Propane (L.P.) Gas Valve
15 --------* Tail Piece Collar ONLY
16 --------* 1 1/2” Union Tail Piece ONLY
17 881367 1 Union Shut Off Body Complete with Tail Piece and Collar
(includes illus. nos. 15 through 17)
18 142800 1 1/2” x 18” Pipe
19 150309 4 #10-16 x 1/2” Hex Head TEK Crimptite Screw
20 318700 2 Pipe Bracket (bent)
21 850850 1 Non-Heat Reclaimer Burner Box ONLY
850861 1 Heat Reclaimer Burner Box ONLY
-------- 1 Burner Assembly Complete Less Orifices
(refer to DSI Burner Assembly Listing on page 65)
22 882627 1 ADC Direct Spark Ignition (DSI) Module ONLY
23 150299 4 #10 x 1” Hex Washer TEK Screw
-- -------- 1 Conversion Kit
(refer to DSI L.P. Conversion Kit Listing on page 65)
* Not available individually...must be purchased as an assembly.
