ADC AD-25 - Manual (Page 35)

33
Telephone: (508) 678-9000 Fax: (508) 678-9447
Illus. No. Part No. Qty. Description
1 100108 1 5L-680 V-Belt (idler to basket [tumbler])
For AD-15
100107 1 5L-670 V-Belt (basket [tumbler] to idler)
For AD-25
2 101129 1 9” x 2-1/2” Compound Pulley
3 100110 1 4L-500 V-Belt (idler to motor)
For AD-15
For AD-25 60 Hz ONLY
100103 1 4L-510 V-Belt (idler to motor)
For AD-25 50 Hz ONLY
4 154301 2 5/16-18 x 1” Allen Setscrew
5 100705 1 3/16” x 3/16” x 1-3/8” Key
6 882576 1 Idler Bearing Assembly Complete
(includes illus. nos. 5 through 12)
7 150617 2 3/8-16 x 1” Hex Head Machine Bolt
8 153005 2 3/8” Lock Washer
9 153004 2 3/8” Flat Washer
10 801009 1 Idler Square Washer
11 152004 1 5/16-18 Hex Nut
12 150509 1 5/16-18 x 3” Hex Head Machine Bolt
AD-15/AD-25 Idler Bearing Assembly
