ASUS P5B SE 2-5
Internal connectors Page
1. Floppy disk drive connector (34-1 pin FLOPPY) 2-26
2. IDE connector (40-1 pin PRI_EIDE) 2-26
3. ICH8 Serial ATA connectors (7-pin SATA1, SATA2,SATA3,
SATA4)
2-27
4. JMicron ® JMB363 Serial ATA RAID connector
(7-pin SATA_RAID)
2-28
5. Digital audio connector (4-1 pin SPDIF_OUT) 2-28
6. USB connectors (10-1 pin USB56, USB 78, USB910) 2-29
7. Optical drive audio connector (4-pin CD) 2-29
8. CPU, chassis, and power fan connectors (4-pin CPU_FAN,
3-pin CHA_FAN, 3-pin PWR_FAN)
2-30
9. Chassis intrusion connector (4-1 pin CHASSIS) 2-30
10. Front panel audio connector (10-1 pin AAFP) 2-31
11. ATX power connectors (24-pin EATXPWR, 4-pin ATX12V) 2-32
12. System panel connector (20-8 pin PANEL) 2-33
ASUS Q-Connector (system panel) 2-34
