PCM-3362 User Manual
64
CN25
I2C BUS connector
Part Number
1653004101
Footprint
HD_4x1P_79_D
Description
PIN HEADER 4*1P 180D(M) 2.0mm DIP WO/Pb
Pin
Pin Name
Signal Type
Signal Level
1
GND
2
I2 C_DAT
I/O
3 I2
C_CLK
I/O
4 +V5_I2C
PWR
+5V
CN26
-12V & -5V power connector
Part Number
1653003101
Footprint
HD_3x1P_79_D
Description
PIN HEADER 3*1P 180D(M)
2.0mm DIP SQUARE W/O Pb
Pin
Pin Name
Signal Type
Signal Level
1
-V5
PWR
-5 V
2
GND
3 -V12
PWR
-12
V
1
2
4
3
