PCM-3362 User Manual 8
This chapter explains the setup procedures of the PCM-3362 hardware, including
instructions on setting jumpers and connecting peripherals, switches and indicators.
Be sure to read all safety precautions before you begin the installation procedure.
2.1 Jumpers
The PCM-3362 has a number of jumpers that allow you to configure your system to
suit your application. The table below lists the functions of the various jumpers.
2.2 Connectors
Onboard connectors link the PCM-3362 to external devices such as hard disk drives,
a keyboard, or floppy drives. The table below lists the function of each of the board's
connectors.
Table 2.1: Jumpers
JP1 CLEAR CMOS
JP2 LVDS Panel Power Select
JP3 COM3 RS422/RS485 Select
JP4 PCI I/O Voltage Select
Table 2.2: Connectors
Label Function
CN1 HD Audio Connector
CN4 SO-DIMM Connector
CN6 LVDS Connected
CN7 Panel Inverter Connector
CN8 VGA Connector
CN9 USB Port0/1 Connector
CN10 USB Port2/3 Connector
CN12 Front panel Connector
CN13 Buzzer Connector
CN15 SATA Connector
CN16 COM1~COM2 Connector
CN17 RS422/485 Connector
CN18 LAN Connector
CN19 LAN LED Connector
CN20 PS2 Keyboard/Mouse Connector
CN21 GPIO Connector
CN23 ATX Power In Connector
CN24 Power In Connector
CN25 I2C BUS connector
CN26 -12 V & -5 V power connector
P1 PC104-plus Connector
BH1 RTC Battery Connector
