Page 16

8.5 Attaching the seal

1. Clean the worktop around the cut out

area.

2. Attach the supplied seal stripe to the

lower edge of the hob along the outer

edge of the glass ceramic. Do not

extend it. Make sure that the ends of

the seal stripe are located in the

middle of one side of the hob.

3. Add some mm when you cut the seal

stripe to the length.

4. Push the two ends of seal stripe

together.

8.6 Assembly

min.
50mm

min.
500mm

R 5mm

min.

55mm

340

490
