Telephone System Configuration
31
CSG SIP Communications Gateway Operation/Reference Guide
Create New User Page Options (Cont.)
Dial Plan
This option references the Dial Plans option on the left tool bar.
Based on the calling rules you’ve created, you can restrict the
outbound dialing of this extension to local calls, emergency calls,
and standard long-distance calls for North America. This option
also possibly allows blocking or allowing international (011 prefix
dialed) calls.
Caller ID
Identifies the Caller ID presented when the listed extension dials
an internal extension.
Outbound Caller
ID
Identifies the Caller ID presented when the listed extension dials
an extenal number. Your ability to manipulate your outbound CID
may be limited by your VoIP provider. Manipulation of CID across
analog trunks is not possible.
Enable Voicemail Builds a voice mail box for the extension that can be reached by
dialing the Check Voicemail extension. The Voicemail extension
can be configured. The current default is 6050.
Voicemail Access
PIN Code
The password used to access voicemail for the specified
extension.
E-Mail Address
Voice mails received by this extension can be sent as audio file
attachments e-mailed to a specific address.
SIP
Identifies whether the extension sends and receives calls using
the VoIP protocol SIP.
IAX
Identifies whether the extension sends and receives calls using
the VoIP protocol IAX.
In Directory
CSG establishes a directory of all extensions so that inbound
callers can reach someone in your office by dialing the first few
digits of the person’s first or last name. The company directory
includes only the name of the extension if you check this option.
SIP
Identifies whether the extension sends and receives calls using
the VoIP protocol SIP.
IAX
Identifies whether the extension sends and receives calls using
the VoIP protocol IAX.
Analog Station
A drop-down menu is available to identify the analog phone port
which this extension will access. If more than one phone is con-
nected to your CSG you may need to confirm the port number
listed on the back of the CSG.
Flash
Flash Timing defines the duration, in milliseconds, that the CSG
will use if it is sending a flash signal to another system.
RXFlash
Receive Flash Time defines the duration, in milliseconds, that the
CSG requires to consider a flash operation that it receives to be
valid.
Codec
Preference
Codecs provide the ability for your voice to be converted to a
digital signal and transmitted across the Internet. The quality of
your call can be affected by the choice you make. The codecs
available to you will depend on what is supported by the service
provider you choose. You can select the order in which the
codecs are used. The codecs commonly available are u-law,
a-law, GSM, G.726, G.722, and G.729A. A registered G.729A
license is required to use the G.729A codec.
MAC Address
The MAC Address field is used to specify the MAC address of a
PolyCom® phone connected to the CSG. The MAC address
associates the phone with this extension and enables the
auto-synchronization of provisioning information.
