Canon VB-M700F - Manual (Page 130)

130
You can configure the way the Viewer starts up, for
example, to have it bypass the login screen with the user
name and password (pp. 41, 42) by creating a shortcut
icon that specifies Viewer startup options.
[Viewer.exe] is located in the following folder by
default:
:\Program Files\Canon\WebView\
NVR30
Note
• corresponds to the drive containing the
system files of the operating system. If the operating system is
installed on the C drive, the system drive is the C drive.
• A message may appear asking whether or not you want to
create a shortcut icon on the desktop. Click [OK] if you want to
create the desktop icon.
When the IP address of a computer that has a Storage
Server installed on it changes, the IP address of the
Storage Server must also be changed.
Example: 64-bit OS
"c:\Program Files (x86)\Canon\WebView\NVR30\
storage_server.exe"-resethost=XXX.XXX.X.XX
Example: 32-bit OS
“c:\Program Files\Canon\WebView\NVR30\
storage_server.exe”-resethost=XXX.XXX.X.XX
Enter the IP address the computer changed to for
“XXX.XXX.X.XX”.
• To stop or start the service from the control panel,
select [RM-Lite Storage Server].
• When executing the command, enter
“storage_server_rm_lite.exe”.
Create a Shortcut Icon for Starting the Viewer
Important
• You cannot reconfigure the shortcut icon that is automatically
created on your desktop when you install this software.
• The login password can be easily viewed in the properties of
the shortcut icon. Make sure to take sufficient security
measures when using this feature.
1 Right-click [Viewer.exe] in the installation folder and
click [Create shortcut].
2 Right-click the shortcut icon and select [Properties].
3 On the [Shortcut] tab, add a startup option to [Target].
Startup Options Description
-group nvr://
:@<
storage server group name> The information in the options
is used to connect to the
server group and start the
Viewer, without displaying the
[Connect to Storage Server
Group] dialog box on startup.
4 Click [OK] to close the dialog box.
5 Move the shortcut icon to a location you prefer.
Changing the Storage Server IP Address
1 Select [RM Storage Server] from [Control Panel] >
[System and Security] > [Administrative Tools] and
stop the service.
2 Open the command prompt using [Run as
administrator], enter the “storage_server.exe”
command name and option (-resethost=“IP address”),
and execute the command.
3 Select [RM Storage Server] from [Control Panel] >
[System and Security] > [Administrative Tools] and
start the service again.
