Installation, Lens Adjustments and Lens Data Tables
36
5200 User’s Manual
Zoom Lens Data Table “continued”
Data presented in the following tables are for reference use only!
2.5-4.0:1 Lens Specification/Throw Distance (Reference Only)
Throw Distance: 16.4 ft (5.0 m) - 131.0 ft. (40.0 m) @ 4:3 Ratio
Pixel Vertical Offset @ 1024 x 768 = +/- 360 pixels
Image Size Throw Distance
Width Height Diagonal Min Max
in. mm in. mm in mm in. ft. m
50 1270 37.5 953 62.5 1588 125 10.4 3.2 200 16.7 5.1
60 1524 45.0 1143 75.0 1905 150 12.5 3.8 240 20.0 6.1
80 2032 60.0 1524 100.0 2540 200 16.7 5.1 320 26.7 8.1
100 2540 75.0 1905 125.0 3175 250 20.8 6.4 400 33.3 10.2
120 3048 90.0 2286 150.0 3810 300 25.0 7.6 480 40.0 12.2
180 4572 135.0 3429 225.0 5715 450 37.5 11.4 720 60.0 18.3
240 6096 180.0 4572 300.0 7620 600 50.0 15.2 960 80.0 24.4
394 10008 295.5 7506 492.5 12510 985 82.1 25.0 1576 131.3 40.0
4.0-7.0:1 Lens Specification/Throw Distance (Reference Only)
Throw Distance: 26.25 ft. (8.0m) - 229.6 ft. (70.0 m)
Pixel Vertical Offset @ 1024 x 768 = +/- 200 pixels
Image Size Throw Distance
Width Height Diagonal Min Max
in. mm in. mm in. mm in. ft. m in. ft. m
90 2286 67.5 1715 112.5 2858 360 30.0 9.1 630 52.5 16.0
102 2591 76.5 1943 127.5 3239 408 34.0 10.4 714 59.5 18.1
128 3251 96.0 2438 160.0 4064 512 42.7 13.0 896 74.7 22.8
256 6502 192.0 4877 320.0 8128 1024 85.3 26.0 1792 149.3 45.5
358 9093 268.5 6820 447.5 11367 1432 119.3 36.4 2506 208.8 63.7
394 10008 295.5 7506 492.5 12510 1576 131.3 40.0 2758 229.8 70.1
630 16002 472.5 12002 787.5 20003 2520 210.0 64.0 N/A N/A N/A
689 17501 516.8 13125 861.3 21876 2756 229.7 70.0 N/A N/A N/A
Preliminary
