Installation, Lens Adjustments and Lens Data Tables
33
5200 User’s Manual
Fixed Lens Data Table
Data presented in the following tables are for reference use only!
1.0:1 Lens Specification/Throw Distance (Reference Only)
Throw Distance: 4.6 ft. (1.4 m) - 30 ft. (9.1 m) @ 4:3 Ratio
Pixel Vertical Offset @ 1024 x 768 = +/- 150 pixels
Image Size
Width Height Diagonal
Throw Distance
in. mm in mm in. mm in. ft. m
55 1397 41.3 1048 68.8 1746 55.0 4.6 1.4
80 2032 60.0 1524 100.0 2540 80.0 6.7 2.0
120 3048 90.0 2286 150.0 3810 120.0 10.0 3.0
180 4572 135.0 3429 225.0 5715 180.0 15.0 4.6
240 6096 180.0 4572 300.0 7620 240.0 20.0 6.1
360 9144 270.0 6858 450.0 11430 360.0 30.0 9.1
2.3:1 Lens Specification/Throw Distance (Reference Only)
Throw Distance: 17.2 ft. (5.5 m) - 110.4 ft. (33.6 m)
Pixel Vertical Offset @ 1024 x 768 = +/- 150 pixels
Image Size
Width Height Diagonal
Throw Distance
in. mm in. mm in. mm in. ft. m
90 2286 67.5 1715 112.5 2858 207 17.3 5.3
102 2591 76.5 1943 127.5 3239 235 19.6 6.0
128 3251 96.0 2438 160.0 4064 294 24.5 7.5
256 6502 192.0 4877 320.0 8128 589 49.1 15.0
358 9093 268.5 6820 447.5 11367 823 68.6 20.9
576 14630 432.0 10973 720.0 18288 1325 110.4 33.6
Preliminary
