Installation, Lens Adjustments and Lens Data Tables
34
5200 User’s Manual
Fixed Lens Data Table “continued”
Data presented in the following tables are for reference use only!
3.9:1 Lens Specification/Throw Distance (Reference Only)
Throw Distance: 19.0 ft. (5.8 m) - 118.0 ft. (36.0 m) @ 4:3 Ratio
Pixel Vertical Offset @ 1024 x 768 = +/- 150 pixels
Image Size
Width Height Diagonal
Throw Distance
in. mm in. mm in mm in. ft. m
58 1483 43.8 1113 73.0 1854 228 19.0 5.8
80 2032 60.0 1524 100.0 2540 312 26.0 7.9
96 2438 72.0 1829 120.0 3048 374 31.2 9.5
120 3048 90.0 2286 150.0 3810 468 39.0 11.9
240 6096 180.0 4572 300.0 7620 936 78.0 23.8
363 9220 272.3 6915 453.8 11525 1416 118.0 36.0
5.5:1 Lens Specification/Throw Distance (Reference Only)
Throw Distance: 26.0 ft (8.0 m) - 164.0 ft. (50.0 m) @ 4:3 Ratio
Pixel Vertical Offset @ 1024 x 768 = +/- 150 pixels
Image Size
Width Height Diagonal
Throw Distance
in. mm in. mm in mm in. ft. m
60 1524 45.0 1143 75.0 1905 330 27.5 8.4
80 2032 60.0 1524 100.0 2540 440 36.7 11.2
100 2540 75.0 1905 125.0 3175 550 45.8 14.0
120 3048 90.0 2286 150.0 3810 660 55.0 16.8
180 4572 135.0 3429 225.0 5715 990 82.5 25.1
240 6096 180.0 4572 300.0 7620 1320 110.0 33.5
358 9093 268.5 6820 447.5 11367 1969 164.1 50.0
Preliminary
