Preliminary – Ampro Corporation DLP 5200 User Manual
Page 37
Installation, Lens Adjustments and Lens Data Tables
35
5200 User’s Manual
Zoom Lens Data Table
Data presented in the following tables are for reference use only!
1.2-2.3:1 Lens Specification/Throw Distance (Reference Only)
Throw Distance: 5.9 ft. (1.8 m) - 70.3 ft. (21.4 m) @ 4:3 Ratio
Pixel Vertical Offset @ 1024 x 768 = 0 pixels
Image Size
Throw Distance
Width
Height
Diagonal
Min
Max
in.
mm
in
mm
in.
mm
in.
ft.
m
in.
ft.
m
60
1524
45.0
1143
75.0
1905
72.0
6.0
1.8
138.0
11.5
3.5
80
2032
60.0
1524
100.0
2540
96.0
8.0
2.4
184.0
15.3
4.7
120
3048
90.0
2286
150.0
3810
144.0
12.0
3.7
276.0
23.0
7.0
180
4572
135.0
3429
225.0
5715
216.0
18.0
5.5
414.0
34.5
10.5
200
5080
150.0
3810
250.0
6350
240.0
20.0
6.1
460.0
38.3
11.7
360
9144
270.0
6858
450.0
11430
432.0
36.0
11.0
828.0
69.0
21.0
2.3-5.5:1 Lens Specification/Throw Distance (Reference Only)
Throw Distance: 19.0 ft. (5.8 m) - 118.0 ft. (36.0 m) @ 4:3 Ratio
Pixel Vertical Offset @ 1024 x 768 = 0 pixels
Image Size
Throw Distance
Width
Height
Diagonal
Min
Max
in.
mm
in.
mm
in
mm
in.
ft.
m
in.
ft.
m
58
1483
43.8
1113
73.0
1854
134
11.2
3.4
321.2
26.8
8.2
80
2032
60.0
1524
100.0
2540
184
15.3
4.7
440.0
36.7
11.2
96
2438
72.0
1829
120.0
3048
221
18.4
5.6
528.0
44.0
13.4
120
3048
90.0
2286
150.0
3810
276
23.0
7.0
660.0
55.0
16.8
240
6096
180.0
4572
300.0
7620
552
46.0
14.0
1320.0
110.0
33.5
257
6528
192.8
4896
321.3
8160
591
49.3
15.0
1413.5
117.8
35.9
1.5-2.5:1 Lens Specification/Throw Distance (Reference Only)
Throw Distance: 17.2 ft. (3.0 m) - 110.4 ft. (25.0 m)
Pixel Vertical Offset @ 1024 x 768 = +/- 360 pixels
Image Size
Throw Distance
Width
Height
Diagonal
Min
Max
in.
mm
in.
mm
in.
mm
in.
ft.
m
80
2032
60.0
1524
100.0
2540
120
10.0
3.0
408.0
34.0
10.4
102
2591
76.5
1943
127.5
3239
153
12.8
3.9
520.2
43.4
13.2
128
3251
96.0
2438
160.0
4064
192
16.0
4.9
652.8
54.4
16.6
192
4877
144.0
3658
240.0
6096
288
24.0
7.3
979.2
81.6
24.9
358
9093
268.5
6820
447.5
11367
537
44.8
13.6
N/A
N/A
N/A
458
11633
343.5
8725
572.5
14542
687
57.3
17.4
N/A
N/A
N/A
558
14173
418.5
10630
697.5
17717
837
69.8
21.3
N/A
N/A
N/A
620
15748
465.0
11811
775.0
19685
930
77.5
23.6
N/A
N/A
N/A
655
16637
491.3
12478
818.8
20796
983
81.9
25.0
N/A
N/A
N/A
Preliminary
