Appendix
23
Symptom: The paper
cassette cover can-
not be closed.
Remedy: The parts indicated by “A” in the
illustration below have locked up.
Refer to the illustration and use the tip of
a ball-point pen to slide the indicated part
in the direction of the arrow to free it
.
Free the part on the opposite side
using the same method
Symptom: The paper
cassette cover came
off.
Remedy: Insert the pins into the white paper
cassette cover holders (at the areas
shown by “B” below) until they snap into
place.
The pin snaps in more easily if the two
parts are angled to form a “V”.
1 2
Paper cassette
cover
A
Push with the tip of a ball-point pen to slide it.
B
