Web Based Management
56
5
Changing the LDAP configuration using a web browser
(For MFC-J2510/J4510DW/J4710DW) (Available as a
download)
5
You can configure and change the LDAP settings using a web browser.
a Click Network on the web page, and then click Protocol.
b Choose the LDAP check box and then click Submit.
c Restart the machine to activate the configuration.
d Make sure the machine is turned on and then choose Advanced Setting on the Protocol page.
Now you can configure and change the following LDAP settings using a web browser.
 LDAP Server Address
 Port (The default port number is 389.)
 Search Root
 Authentication
 Username
 Password
 Timeout for LDAP
 Attribute of Name (Search Key)
 Attribute of E-mail
 Attribute of Fax Number
e
After setting, make sure that the Status is Enabled. Then click Submit.
NOTE
For the details of each item, see the Help Text in the Web Based Management.
