167
FBDIMM module population order
Single and dual channel population
The tables below list the suggested FBDIMM module population for
normal configuration.
Population with one memory board
Population with two memory boards
DIMM slot Memory board A Memory board B Memory board C Memory board D
Total
memory
1 to 2 2 x 1 GB 2 GB
1 to 4 4 x 1 GB 4 GB
1 to 6 6 x 1 GB 6 GB
1 to 8 8 x 1 GB 8 GB
1 to 2 2 x 2 GB 4 GB
1 to 4 4 x 2 GB 8 GB
1 to 6 6 x 2 GB 12 GB
1 to 8 8 x 2 GB 16 GB
1 to 2 2 x 4 GB 8 GB
1 to 4 4 x 4 GB 16 GB
1 to 6 6 x 4 GB 24 GB
1 to 8 8 x 4 GB 32 GB
DIMM slot Memory board A Memory board B Memory board C Memory board D
Total
memory
1 to 2 2 x 1 GB 2 x 1 GB 4 GB
1 to 4 4 x 1 GB 4 x 1 GB 8 GB
1 to 6 6 x 1 GB 6 x 1 GB 12 GB
1 to 8 8 x 1 GB 8 x 1 GB 16 GB
1 to 2 2 x 2 GB 2 x 2 GB 8 GB
1 to 4 4 x 2 GB 4 x 2 GB 16 GB
1 to 6 6 x 2 GB 6 x 2 GB 24 GB
1 to 8 8 x 2 GB 8 x 2 GB 32 GB
1 to 2 2 x 4 GB 2 x 4 GB 16 GB
1 to 4 4 x 4 GB 4 x 4 GB 32 GB
1 to 6 6 x 4 GB 6 x 4 GB 48 GB
1 to 8 8 x 4 GB 8 x 4 GB 64 GB
