External connection – APC 60-80kW User Manual
Page 25
External Connection
990-4051
Installation Guide APC Silcon 60-80kW 400V UPS
25
UPS Shut Down RS-232 Input or
Advanced Mode RS-232 Data RX In
Line Fail RS-232 Output or
Advanced Mode RS-232 Data TX Out
Unregulated
+24 VDC Output
Normally Open
Line Fail Signal
Normally Open
Low Battery Signal
Normally Closed
Line Fail Signal
Common
Chassis
