Installation Guide APC Silcon 60-80kW 400V UPS
990-4051
External Connection
4.0 External Connection
4.1
Connecting the UPS
CAUTION!
This UPS unit is an EN 50091-2 product and may cause radio interference in a domestic
environment. Take preventive measures if necessary.
CAUTION!
At a switch mode load of 100% the neutral must be rated for 200% output phase current.
System Integration
Interface
Communication
Interface
Relay board (Optional)
Parallel Controller
Output
Input
Ext. batteries
