Sterlco GC Series Central Chiller - Manual (Page 62)

GC Series Central Chillers Chapter 7: Appendix 62 of 79
40 TON (GCWC-140)
PERFORMANCE (NOMINAL DESIGN CONDITIONS)
COOLING CAPACITY 43.35 TONS ALTITUDE SEA LEVEL
COOLANT SUPPLY
TEMPERATURE
50 °F COMPRESSOR POWER 32685 WATTS
CONDENSER INLET WATER
TEMP
85 °F EER 15.92 BTU/WATT
COOLANT WATER CONDENSER WATER FLOW 130 GPM
COOLANT FLOW 104 GPM SOUND POWER LEVEL 79 dBA
UNIT PRESSURE DROP 7 PSID
SOUND PRESS LEVEL @ 1
METER
dBA
OPERATING PARAMETERS
COOLANT SUPPLY
TEMPERATURE
20-80 °F COOLANT FLOW 48-192 GPM
CONDENSER INLET WATER
TEMP
50-90 °F MINIMUM LOAD 8.67 TONS
SPECIFICATIONS
COMPRESSOR SCROLL FRAME GALVANIZED STEEL
EVAPORATOR BRAZED PLATE COOLANT CIRCUIT NON-FERROUS
CONDENSER
SHELL &
TUBE
REFRIGERANT 42 LBS R-410A
EVAPORATOR FILTER 20 MESH WEIGHT (OPERATING) 2856.9 LBS
POWER 460V/3PH/60HZ WEIGHT (SHIPPING) 1604.9 LBS
CONTROL CIRCUIT 24/120 VAC ELECTRICAL ENCLOSURE NEMA 4/12
COMPRESSOR RATED LOAD
AMPS
(2) @ 30.4 AMPS EACH CONTROL MICROPROCESSOR
50 TON (GCWC-175)
COOLING CAPACITY 54.46 TONS ALTITUDE SEA LEVEL
COOLANT SUPPLY
TEMPERATURE
50 °F COMPRESSOR POWER 41633 WATTS
CONDENSER INLET WATER
TEMP
85 °F EER 15.70 BTU/WATT
COOLANT WATER CONDENSER WATER FLOW 163 GPM
COOLANT FLOW 130 GPM SOUND POWER LEVEL 82 dBA
UNIT PRESSURE DROP 7 PSID
SOUND PRESS LEVEL @ 1
METER
dBA
OPERATING PARAMETERS
COOLANT SUPPLY
TEMPERATURE
20-80 °F COOLANT FLOW 60-240 GPM
CONDENSER INLET WATER
TEMP
50-90 °F MINIMUM LOAD 10.89 TONS
SPECIFICATIONS
COMPRESSOR SCROLL FRAME GALVANIZED STEEL
EVAPORATOR BRAZED PLATE COOLANT CIRCUIT NON-FERROUS
CONDENSER
SHELL &
TUBE
REFRIGERANT 44 LBS R-410A
EVAPORATOR FILTER 20 MESH WEIGHT (OPERATING) 3023.7 LBS
POWER 460V/3PH/60HZ WEIGHT (SHIPPING) 1763.7 LBS
CONTROL CIRCUIT 24/120 VAC ELECTRICAL ENCLOSURE NEMA 4/12
COMPRESSOR RATED LOAD
AMPS
(2) @ 41.9 AMPS EACH CONTROL MICROPROCESSOR
