GC Series Central Chillers Chapter 7: Appendix 59 of 79
60 TON (GCRC-210)
PERFORMANCE (NOMINAL DESIGN CONDITIONS)
COOLING CAPACITY 63.95 TONS ALTITUDE SEA LEVEL
COOLANT SUPPLY
TEMPERATURE
50 °F COMPRESSOR POWER 63589 WATTS
AMBIENT AIR TEMPERATURE 95 °F EER 12.07 BTU/WATT
COOLANT WATER
COOLANT FLOW 153 GPM SOUND POWER LEVEL 99 dBA
UNIT PRESSURE DROP 7 PSID
SOUND PRESS LEVEL @ 1
METER
dBA
OPERATING PARAMETERS
COOLANT SUPPLY
TEMPERATURE
20-80 °F COOLANT FLOW 72-288 GPM
AMBIENT AIR TEMPERATURE 60-115 °F MINIMUM LOAD 12.79 TONS
SPECIFICATIONS
COMPRESSOR SCROLL FRAME GALVANIZED STEEL
EVAPORATOR BRAZED PLATE COOLANT CIRCUIT NON-FERROUS
EVAPORATOR FILTER 20 MESH WEIGHT (OPERATING) 2463.4 LBS
POWER 460V/3PH/60HZ WEIGHT (SHIPPING) 1297.4 LBS
CONTROL CIRCUIT 24/120 VAC ELECTRICAL ENCLOSURE NEMA 4/12
COMPRESSOR RATED LOAD
AMPS
(2) @ 54.5 AMPS EACH CONTROL MICROPROCESSOR
60 TON (GCRC-210)
SPECIFICATIONS
AMBIENT TEMPERATURE
RANGE
-20 to 115 °F SOUND POWER LEVEL 99 dBA
CONDENSER AIR FLOW 50748 CFM
SOUND PRESS LEVEL @ 1
METER
dBA
CONDENSER ALUMINUM FRAME GALVANIZED STEEL
CONDENSER FANS (4) 32 INCH AXIAL PANELS
POWDER COATED
STEEL
CONDENSER FAN MOTOR
(4) 2 HP OAO, 1140 RPM, 3.4
FLA
WEIGHT (SHIPPING) 1369 LBS
POWER 460V/3PH/60HZ
