GC Series Central Chillers Chapter 7: Appendix 57 of 79
40 TON (GCRC-140)
PERFORMANCE (NOMINAL DESIGN CONDITIONS)
COOLING CAPACITY 40 TONS ALTITUDE SEA LEVEL
COOLANT SUPPLY
TEMPERATURE
50 °F COMPRESSOR POWER 38153 WATTS
AMBIENT AIR TEMPERATURE 95 °F EER 12.58 BTU/WATT
COOLANT WATER
COOLANT FLOW 96 GPM SOUND POWER LEVEL 98 dBA
UNIT PRESSURE DROP 7 PSID
SOUND PRESS LEVEL @ 1
METER
dBA
OPERATING PARAMETERS
COOLANT SUPPLY
TEMPERATURE
20-80 °F COOLANT FLOW 48-192 GPM
AMBIENT AIR TEMPERATURE 60-115 °F MINIMUM LOAD 8.00 TONS
SPECIFICATIONS
COMPRESSOR SCROLL FRAME GALVANIZED STEEL
EVAPORATOR BRAZED PLATE COOLANT CIRCUIT NON-FERROUS
EVAPORATOR FILTER 20 MESH WEIGHT (OPERATING) 2236 LBS
POWER 460V/3PH/60HZ WEIGHT (SHIPPING) 1070 LBS
CONTROL CIRCUIT 24/120 VAC ELECTRICAL ENCLOSURE NEMA 4/12
COMPRESSOR RATED LOAD
AMPS
(2) @ 30.4 AMPS EACH CONTROL MICROPROCESSOR
40 TON (GCRC-140)
SPECIFICATIONS
AMBIENT TEMPERATURE
RANGE
-20 to 115 °F SOUND POWER LEVEL 98 dBA
CONDENSER AIR FLOW 38061 CFM
SOUND PRESS LEVEL @ 1
METER
dBA
CONDENSER ALUMINUM FRAME GALVANIZED STEEL
CONDENSER FANS (3) 32 INCH AXIAL PANELS
POWDER COATED
STEEL
CONDENSER FAN MOTOR
(3) 2 HP OAO, 1140 RPM, 3.4
FLA
WEIGHT (SHIPPING) 927 LBS
POWER 460V/3PH/60HZ
