FUTEK IHH500 Series - Manual (Page 6)

6
Wiring Layout
POWER CONNECTIONS
PIN SYMBOL
1 12V
2 Ground
Note: These pins are not polarity sensitive.
OUTPUT CONNECTIONS
PIN SYMBOL DESCRIPTION
1 IDAC analog current output signal
2 REFERENCE analog voltage output return
3 +R1 solid state relay 1 (positive)
4 VDAC analog voltage output signal
5 +R2 solid state relay 2 (positive)
6 GND analog current output return
7 –R1 solid state relay 1 (negative)
8 –R2 solid state relay 2 (negative)
USB PORT CONNECTIONS
PIN SYMBOL
1 VBUS
2 –D
3 +D
4 GND
