Ex. If you are using your CSG110 with a tension and compression load cell and you
have tension setup as the positive direction, but now you would like to have
compression as the positive direction, all you have to do is flip the DIP switch from the
default polarity position to the reverse polarity position.
UP reverse
DOWN straight
SW2: Polarity
Gain
There are eight gain settings available on the CSG110: from 0.5 mV/V to 10 mV/V. The
default setting is configured to 2 mV/V. Select the value closest to your input range by
flipping the DIP switches to the appropriate configuration.
Ex. If you are using a 2 mV/V sensor with the 5 VDC excitation, then you would want to
use configuration 2 for 1 mV/V. If you are using a 2mV/V sensor with 10 VDC
excitation then you would want to use configuration 4 for 2 mV/V.
