Secure Menu
Press the INDEX key for 5 Seconds to start the menu. Press INDEX to advance
to the next menu item. Press UP ARROW or DOWN ARROW to change the
value in the display. Press ENTER to retain the value. OUTPUTS ARE DISABLED
(TURNED OFF) WHILE CONTROL IS IN THE SECURE MENU.
SECr
Security Code: See the Security Level Selection and the Password Table on
page 10, in order to enter the correct password. Factory Default is
4
.
SCAH
Scale High: Select
100
to
9999
counts above
SCAL
. The total span between
SCAL
and
SCAH
must be within 11998 counts. Maximum setting range is
-1999
to
+
9999
counts. Factory Default is
23.1
.
SCAL
Scale Low: Select
100
to
9999
counts below
SCAH.
The total span between
SCAL
and
SCAH
must be within 11998 counts. Maximum setting range is
-1999
to
+
9999
counts. Factory Default is
0.0
.
dPt
Decimal Point Positioning: Select
0
,
0.0
,
0.00
, or
0.000
. All Menu items related
to the input will be affected. Factory default is
0.0
.
S1St
Set Point 1 State: Select
P1n
or
P0ut
. Factory default is
P0ut
..
P1n
Pump In (Direct Action). As the input increases the output
will increase.
P0ut
Pump Out (Reverse Action). As the input increases the output
will decrease.
S2St
Set Point 2 State: Select
P1n
,
P0ut
or
0FF
. Factory default is
P0ut.
P1n
Pump In (Direct Action). As the input increases the output
will increase.
P0ut
Pump Out (Reverse Action). As the input increases the output
will decrease.
0FF
This setting is for applications when the MPC is used with only one
pump systems. All Menu items relating to Set Point 2 will not
appear.
LdL9
Lead / Lag: Select
0n
or
0FF
. Factory default is
0n
. (See page 11)
0n
The Lead/Lag function is enabled. The outputs of
SP1
and
SP2
will alternate.
0FF
The Lead/Lag function is disabled.
1nPC
Input Correction: Select ±500 counts. This feature allows the input value to
be changed to agree with an external reference or to compensate for
sensor error. Note:
1nPC
is reset to zero when the input type is changed, or
when decimal position is changed.
