37
APPENDIX 5
CALIBRATION TABLE: GAS DEPENDENT VARIABLES
INDEX NAME
DATA
TYPE
NOTES
0 BlankSDPROC char[10] Do not modify. For internal use only.
1 SerialNumber char[20]
2 ModelNumber char[20]
3 SoftwareVer char[10]
4 TimeSinceCalHr float Time since last calibration in hours.
5 Options uint Misc. Options.
6 AOutOffset_mA int
7 AddressRS485 char[3] Two character address for RS485 only.
8 AInScaleV float
9 AInOffsetV float
10 AInScale_mA float
11 AInOffset_mA float
12 AoutScaleV float
13 AoutScale_mA float
14 SensorZero uint
15 Klag[0] float
16 Klag[1] float
17 Klag[2] float
18 Klag[3] float
19 Klag[4] float
20 Klag[5] float
21 Reserved float
22 Reserved float
23 Reserved float
24 Reserved float
25 Reserved float
26 Reserved float
27 Kgain[0] float
28 Kgain[1] float
