Series 3050 Btu Monitor
Series 3050 Btu Monitor Programming
The user can program the flow sensor from the front panel by entering a "K" and offset or only a "K" factor, depending on the
flow sensor used.
Programming is menu driven. All data is entered using the LCD/keypad interface. A password gate is included to prevent
unauthorized access to programming parameters. Programming flexibility is extended to units of measure. In addition to
several factory units of measure, the 3000 Series software permits the custom units for rate and total to be created by the
installer.
The Series 3050 provides one Form C solid-state relay, and one solid-state switch output. Both are fully programmable as
either Pulse/Volume, or Set Point control-based Flow Rate, Flow Total, Energy Rate, Energy Total, Temperature 1, Temperature
2 or Delta T. For pulse output, the installer can program both the resolution and the pulse width. Set Point control is extremely
versatile with fully independent set and release points, each with its own time delay.
LEDs located on the front panel indicate status of both the relay and pulse outputs.
All calibration information, units of measure and flow totals are stored in a non-volatile memory that does not require battery
backup for data retention.
Available options:
• Analog Output
• USB
• RS485
• BACnet™
• Modbus®
• Wall Mounting
3050 Series Ordering Matrix
Example: 3050 - x x
Series
Btu Monitor 3050 -
Outputs No Option 0
Analog Output, plus RS485 with
BACnet and Modbus, and USB
1
Mounting
Panel Mount, NEMA 4x Front Panel
0
Wall Mount, NEMA 4x 1
