95
Telephone: (508) 678-9000 Fax: (508) 678-9447
Pneumatic Panel Assembly
1-Way Tilt
For Models Mfd. prior to February 13, 1997
Illus. No. Part No. Qty. Description
1 100564 2 5-Port/3-Position 1/2” N.P.T. Valve
2 100475 1 Valve Stack Assembly
3 100464 1 3/8” N.P.T. Air Jet Valve
4 143159 1 3/8” M.P.T. x 90° Male Elbow
5 141212 1 Stainless Steel Air Jet Tube
6 153018 4 1/4” Flat Washer
7 150513 6 1/4-20 x 2-1/4” Hex Head Machine Bolt
8 153007 8 1/4” Lock Washer
9 143251 1 3/8” M.P.T. Brass Plug
10 143241 4 3/8” Close Brass Nipple
11 143120 10 3/8” O.D. Poly-Flo Tubing (sold by the foot)
12 143161 1 1/8” x 2” Brass Nipple
13 143283 5 3/8” M.P.T. Straight Brass Connector
14 143160 1 3/8” to 1/8” Reducing Bushing
15 100520 2 1/8” N.P.T. Silencer (muffler)
16 143236 1 3/8” F.P.T. Brass Pipe Cross
17 143213 5 3/8” M.P.T. x 90° Elbow
18 100462 2 3/8” M.P.T. Silencer (muffler)
19 881952 1 1 Door/1-Way Tilt Pneumatic Panel Assembly Complete
(includes illus. nos. 1 through 25)
881951 1 2 Door/1-Way Tilt Pneumatic Panel Assembly Complete
(includes illus. nos. 1 through 25)
846786 1 Pneumatic Panel ONLY
20 143206 2 3/8” Flow Control
21 120501 1 1” Jiffy Clip
22 331872 1 2-Position Flow Control Mounting Bracket
23 331872 1 Flow Control Mounting Plate
24 150522 1 1/4-20 x 1/2” Hex Head Washer TEK Screw
25 100477 4 1/4” O.D. Tubing Saddle Block
