109
Telephone: (508) 678-9000 Fax: (508) 678-9447
Main Electrical Panel Upper Component Assembly
Illus. No. Part No. Qty. Description
1 846831 1 Electrical Panel Assembly
2 882266 1 Omega Resistance Temperature Detector (RTD) to Moore Resistance
Temperature Detector (RTD) Conversion Kit
882607 1 Resistance Temperature Detector (RTD) Transmitter Programmed
3 881954 1 110 VAC/24 VDC Power Supply Assembly
132031 1 110 VAC/24 VDC Power Supply ONLY
4 152000 2 #6-32 Hex Nut
5 153010 2 #6 Star Washer
6 847314 1 System Clock - 24 VAC
7 153562 2 #6-32 x 3/4” Clinch Stud
8 847360 1 Digital Temperature Controller Assembly - °F
825015 1 Digital Temperature Controller Assembly - °C
9 847357 1 Hi-Temperature Alarm Assembly - °F
881037 1 Hi-Temperature Alarm Assembly - °C
10 121126 1 Stainless Steel Duplex Receptacle Cover
11 121125 1 Duplex Receptacle
12 152000 4 #6-32 Hex Nut
13 121104 1 4” x 2-1/8” x 1-7/8” Single Outlet Box
14 121400 1 7/8” Universal Bushing
15 153562 4 #6-32 x 3/4” Clinch Stud
16 820685 1 Hi-Limit Controller Bracket
17 132013 1 1-KVA Control Transformer - 240-480v 60 Hz
132014 1 1-KVA Control Transformer - 208v 60 Hz /190/440v 50 Hz
18 150522 4 1/4-20 x 1/2” Hex Head Washer TEK Screw
19 150103 2 #8-32 x 3/4” Phillips Round Head Machine Screw
20 132091 1 208-240 Volt Transformer
132092 1 380 Volt Transformer
132078 1 480 Volt Transformer
(for models mfd. as of March 19, 1997)
132005 1 480 Volt Transformer
(for models mfd. prior to March 19, 1997)
21 123000 2 Red Pilot Light
22 141066 1 Relay Base
23 121400 1 7/8” Universal Bushing
24 150103 2 #8-32 x 3/4” Phillips Round Head Machine Screw
25 141065 1 Burner Controller
26 121400 2 7/8” Universal Bushing
27 150103 1 #8-32 x 3/4” Phillips Round Head Machine Screw
28 123224 1 120 VAC 1-Second Flasher
29 154100 1 #8-32 Rivet Nut
30 150103 4 #8-32 x 3/4” Phillips Round Head Machine Screw
31 153050 4 1/2” Flat Washer
32 153026 4 1/2” Lock Washer
33 152011 4 1/2-13 Hex Nut
34 120765 2 End Stop Bracket
For Gas Models ONLY
