Illus. No.
Part No.
Qty.
Description
1
331752
1
Steam Trap Bracket
2
153018
6
1/4” Flat Washer
3
150522
6
1/4” Hex Head Washer TEK Screw
4
150522
4
1/4” Hex Head Washer TEK Screw
5
143195
2
1-1/4” Pipe Clip
6
165225
1
1-1/4” Inverted Steam Trap
7
331752
1
Steam Trap Bracket
8
142565
1
1-1/4” x 3” Long Nipple
9
142558
1
1-1/4” Union
10
142565
2
1-1/4” x 3” Nipple
11
142562
1
1-1/4” x 10” Nipple
12
142554
2
1-1/4” x 90° Elbow
13
142713
1
1-1/4” Close Nipple
14
143119
1
1 x 11-3/4” Long Flex Hose
15
142554
1
1-1/4” x 90° Elbow
16
142558
1
1-1/4” Union
17
142713
2
1-1/4” Close Nipple
18
142558
2
1-1/4” Union
19
142713
3
1-1/4” Close Nipple
20
142558
1
1-1/4” Union
21
142922
1
1-1/4” Tee
22
142713
1
1-1/4” Close Nipple
23
142520
2
2” x 11-1/4” Reducing Bushing
24
142713
2
1-1/4” Close Nipple
25
142558
2
1-1/4” Union
26
143119
2
1-1/4” x 11-3/8” Flex Hose
27
142558
2
1-1/4” Union
28
142559
2
1-1/4” x 6” Long Nipple
29
142554
2
1-1/4” x 90° Elbow
30
142713
2
1-1/4” Close Nipple
31
142520
2
2” x 1-1/4” Reducing Bushing
32
165040
8
Steam Coil
33
142517
8
2” Close Nipple
34
142542
4
2” Union
35
142524
2
2” Tee
36
142519
1
2” Street Elbow
37
142595
1
2” x 7” Nipple
38
142594
1
2” x 10-1/8” Nipple
39
142541
1
2” x 90° Elbow
40
142595
1
2” x 7” Nipple
41
142542
3
2” Union
42
143128
3
2” x 13” Flex Hose
43
142921
1
2” x 2” x 2-1/2” Tee
44
142836
1
2” x 2-1/2” Nipple
45
142541
1
2” x 90° Elbow
46
142519
1
2” Street Elbow
Steam Coil Piping Assembly
For Steam Models ONLY
