Left lint drawer/basket assembly – ADC AD-464 User Manual
Page 42
40
American Dryer Corporation
88 Currant Road / Fall River, MA 02720-4781
Left Lint Drawer/Basket Assembly
Illus. No.
Part No.
Qty.
Description
1*
881265
1
Left Lint Drawer/Basket Assembly Complete
(includes illus. nos. 1 through 4)
2
331421
1
Lint Drawer/Basket Magnet Holder
3
154200
3
5/32” Rivet
4
102109
1
7/8” x 1/2” x 1/2” Magnet
5
108217
1
Lint Drawer/Basket Screen Assembly
6
150108
5
#8-32 x 1/2” Phillips Pan Head Machine Screw
7
346492
1
Base Lint Drawer/Basket Felt Strip
8
115989
1
Base Lint Drawer/Basket Felt
9
153012
5
#8 Star Washer
10
152001
5
#8-32 Hex Nut
11
346650
1
Lint Drawer/Basket Felt Stiffener
*
Specify color when ordering.
