59
Telephone: (508) 678-9000 Fax: (508) 678-9447
Illus. No. Part No. Qty. Description
1 142744 1 1” x 12” Nipple
2 331417 1 Sprinkler Pipe Bracket
3 154350 1 U-Bolt for 1” Pipe
4 143556 1 1” F.P.T. Ball Valve
5 142808 1 1” x 3” Nipple
6 100565 1 Sprinkler Valve
(for models mfd. as of July 25, 1996)
881414 1 Sprinkler Valve
(for models mfd. prior to July 25, 1996)
100567 1 Sprinkler Valve Rebuilt Kit
7 143210 1 1/4” M.P.T. Compression Elbow
8 142598 1 1” x 17” Nipple
9 142548 1 1” x 90° Elbow
10 142746 1 1” x 24” Nipple
11 154350 2 U-Bolt for 1” Pipe
12 142808 1 1” x 3” Nipple
13 142548 2 1” x 90° Elbow
14 143137 2 13/16-1 x 3/4” Hose Clamp
15 143136 2 1” I.D. Steel Air Hose Nipple
16 143135 1 1” I.D. x 4’ Super Flex Rubber Hose
17 152002 6 1/4-20 Hex Nut
18 153007 6 1/4” Lock Washer
19 346535 2 Basket (tumbler) Base Sprinkler Pipe Mounting Bracket
20 142548 1 1” x 90° Elbow
21 142587 1 1” x 27-1/2” Nipple
22 331419 1 Top Sprinkler Pipe Bracket
23 152002 4 1/4-20 x 1” Hex Nut
24 153007 4 1/4” Lock Washer
25 150511 6 1/4-20 x 1” Hex Head Machine Bolt
26 142602 1 1” Union
27 154350 1 U-Bolt for 1” Pipe
Lower Sprinkler Assembly
