SPECIFICATIONS
External Power
Input Voltage
8 5…30V DC (diode protected)
Maximum Current Draw 18 mA (using internal resistor @ 30V DC input)
Environmental
Operating Temperature
–22…158° F (–30…70° C)
Inputs (Magnetic Pickup)
Frequency Range
0…4000 Hz
Trigger Sensitivity 30 mV p-p…30V p-p
Output Signal
Max Voltage
30V DC
Max Power 0 25 W
Pulse Output (using internal pullup resistor)
Maximum Current
8 mA
VH = Power input voltage – 0 7V DC
VL = Less then 0 4V @ maximum input power
Internal Pullup Resistor 3 6 kΩ (enabled/disabled by jumper)
Pulse Output (using external pullup resistor)
Maximum Current
100 mA
VH = Input voltage to external pullup resistor
VL = [VH /(selected resistor value + 47 Ω)] × 47 Ω
Pulse Length 150 µs, 1 ms, 25 ms, 100 ms, 500 ms, 1 s, or auto mode
Enclosure Killark aluminum capped elbow Y-3
Agency Listings
CSA
Hazardous Locations
Class I, Div 1, Groups B, C and D; Class II, Groups E, F, and G; and Class III
Type 4X; T6 @ 70° C
C22 2 No 30 for Canada
Pollution Degree 2
Normally only non-conductive pollution occurs Occasionally, a temporary conductivity
caused by condensation must be expected
Overvoltage Category III Distribution level, fixed installation, with smaller transient overvoltage than installation
category IV (Primary supply level)
MPORTANT I
For this CSA rating to be valid, the circuit board must be mounted in a certified Killark one inch model Y-3 conduit outlet box.
Signal Conditioner, B220-885 K Factor Scaler and B220-900 Programming Software Kit
