TROUBLESHOOTING
Problem Possible Causes Remedies
Screen is blank Battery is dead Replace battery
Will not count in totalizer mode 1 Improperly programmed
2 Broken or defective wiring
3 Improperly connected
4 Transmitter defective 1 Check programming
2 Check wiring
3 Check connections
4 Repair or replace transmitter
Will not indicate rate of flow 1 Improperly programmed
2 Improperly connected
3 Transmitter defective 1 Check programming
2 Check connections
3 Repair or replace transmitter
Cannot program Program-enable jumper is not installed or
is installed improperly
Install jumper from Terminal 1 to
Terminal 5
Cannot reset from front panel Reset enable is not programmed Reprogram mode to R
(Program Mode 6)
Erroneous readings 1 Improperly programmed
2 Defective transmitter 1 Check programming
2 Repair or replace transmitter
Table 4: Troubleshooting
For further assistance, call our Technical Support Staff at 1-800-876-3837
Model ER-10, ER-10/R & ER-10H Industrial Register
Page 12 September 2013
