Chillers ultima water cooled, General specification – Airedale Ultima Water Cooled 75kW - 450kW User Manual
Page 31
Chillers
ULTIMA WATER COOLED
Chillers
31
Technical Manual : Part No 6259477 V1.4.0_07_2014
General Specification
POINT LOADINGS, WEIGHTS & CENTRE OF GRAVITY (C OF G)
Model D
P1
P2
P3
P4 Operating Weight C of G1 (m)
C of G2 (m)
UWC75D
kg
165
165
245
245
820
380
720
UWC100D
kg
175
175
265
265
880
380
720
UWC125D
kg
180
180
275
275
910
380
730
UWC150D
kg
255
255
380
380
1270
380
850
UWC175D
kg
275
275
415
415
1380
380
850
UWC200D
kg
300
300
445
445
1490
380
850
UWC225D
kg
315
315
475
475
1580
380
860
UWC240D
kg
560
560
340
340
1490
1624
450
UWC250D
kg
330
330
495
495
1650
380
860
UWC270D
kg
610
610
380
380
1830
1721
450
UWC300D
kg
670
670
420
420
2180
1723
450
UWC330D
kg
690
690
460
460
2300
1739
450
UWC360D
kg
720
720
490
490
2420
1744
450
UWC400D
kg
760
760
550
550
2620
1760
450
UWC450D
kg
810
810
600
600
2820
1765
450
Model DQ
P1
P2
P3
P4 Operating Weight C of G1 (m)
C of G2 (m)
UWC75DQ
kg
170
170
255
255
850
380
720
UWC100DQ
kg
180
180
270
270
900
380
720
UWC125DQ
kg
190
190
280
280
940
380
720
UWC150DQ
kg
260
260
390
390
1300
380
850
UWC175DQ
kg
285
285
425
425
1420
380
850
UWC200DQ
kg
305
305
460
460
1530
380
850
UWC225DQ
kg
325
325
485
485
1620
380
860
UWC240DQ
kg
580
580
360
360
1560
1720
450
UWC250DQ
kg
340
340
505
505
1690
380
860
UWC270DQ
kg
630
630
400
400
1900
1726
450
UWC300DQ
kg
680
680
440
440
2240
1731
450
UWC330DQ
kg
710
710
480
480
2380
1742
450
UWC360DQ
kg
740
740
510
510
2500
1747
450
UWC400DQ
kg
780
780
560
560
2680
1758
450
UWC450DQ
kg
830
830
620
620
2900
1767
450
Model DSQ
P1
P2
P3
P4 Operating Weight C of G1 (m)
C of G2 (m)
UWC75DSQ
kg
175
175
265
265
880
380
720
UWC100DSQ
kg
190
190
280
280
940
380
720
UWC125DSQ
kg
195
195
295
295
980
380
730
UWC150DSQ
kg
270
270
400
400
1340
380
850
UWC175DSQ
kg
290
290
435
435
1450
380
850
UWC200DSQ
kg
310
310
470
470
1560
380
850
UWC225DSQ
kg
330
330
495
495
1650
380
860
UWC240DSQ
kg
590
590
360
360
1580
1716
450
UWC250DSQ
kg
345
345
520
520
1730
380
860
UWC270DSQ
kg
640
640
400
400
1920
1722
450
UWC300DSQ
kg
690
690
450
450
2280
1733
450
UWC330DSQ
kg
710
710
480
480
2380
1742
450
UWC360DSQ
kg
740
740
510
510
2500
1747
450
UWC400DSQ
kg
790
790
570
570
2720
1759
450
UWC450DSQ
kg
830
830
620
620
2900
1767
450
1
For C of G diagram refer to
