Chillers
ULTIMA WATER COOLED
Chillers
29
Technical Manual : Part No 6259477 V1.4.0_07_2014
General Specification
DIMENSIONS
UWC75
– UWC250 (EXCEPT UWC240)
20mm Ø
Mounting Holes
Condenser
Water Out
Condenser
Water in
Evaporator
Water Out
Evaporator
Water in
A
760
1850
F
E
D
C
B
G
H
J
P1
P2
P3
P4
C of G2
C of
G
1
Mains Electric
Isolator
Mains Cable
Entry
Controls
Panel
Water Connections
UWC75 - 100
Evap 40mm
Cond 65mm
UWC125
Evap 65mm
Cond 65mm
UWC150 - 200
Evap 65mm
Cond 80mm
UWC225 - 250
Evap 80mm
(Ex. 240)
Cond 80mm
50
50
Model Size
A
B
C
D
E
F
G
H
J
UWC75
mm
1800
428
308
482
397
710
462
876
462
UWC100
mm
1800
428
308
482
397
710
462
876
462
UWC125
mm
1800
383
397
438
397
710
462
876
462
UWC150
mm
2000
380
397
325
628
710
462
1076
462
UWC175
mm
2000
380
397
325
628
710
462
1076
462
UWC200
mm
2000
380
397
325
628
710
462
1076
462
UWC225
mm
2000
268
628
207
628
710
462
1076
462
UWC250
mm
2000
268
628
207
628
710
462
1076
462
