Technical Manual : Part No 6259477 V1.4.0_07_2014
General Specification
MECHANICAL DATA
UWC75 UWC100 UWC125 UWC150 UWC175
Duty – Cooling
Cooling Only (1) kW 87.5 118.9 152.0 184.2 213.1
Nominal Input (1) kW 22.0 29.3 37.4 45.0 50.7
EER (2) 4.0 4.1 4.1 4.1 4.2
Capacity Steps % 0-25-50-75-100 0-25-50-75-100 0-25-50-75-100 0-25-50-75-100 0-20-30-50-70-80-100
Dimensions - H x L x W mm 1850 x 1800 x 760 1850 x 2000 x 760
Weight
Machine - D kg 810 865 890 1240 1345
- DQ kg 840 885 920 1270 1385
- DSQ kg 870 925 960 1310 1415
Operating - D kg 820 880 910 1270 1380
- DQ kg 850 900 940 1300 1420
- DSQ kg 880 940 980 1340 1450
Construction - Material / Colour Plain Galvanised Steel Base with Galvanised Sheet Steel, Epoxy Baked Powder Paint
Superstructure – Light Grey (RAL 7035)
Evaporator Brazed Plate
Insulation Class 0
Quantity 1 1 1 1 1
Water Volume l 3.7 5.1 9.4 11.0 12.3
Total Max. Water Flow l/s 6.1 8.2 10.5 12.7 14.7
Condenser Brazed Plate
Insulation Class 0
Quantity 1 1 1 1 1
Water Volume l 7.2 9.4 11.4 18.5 23.0
Total Max. Water Flow l/s 7.3 9.8 12.6 15.2 17.4
Compressor Tandem Scroll - Hermetic
Quantity 4 4 4 4 4
Oil Charge Volume (Total) l 4 x 4.1 4 x 4.1 4 x 4.1 4 x 4.1 4.7 + 4.1 + 4.7 + 4.1
Oil Type Polyol Ester
Refrigeration Dual Circuit
Refrigerant Control Electronic Expansion Valve
Refrigerant Precharged R407C
Charge (Total) kg 4.9 + 4.9 6.0 + 6.0 8.0 + 8.0 11.4 + 11.4 13.2 + 13.2
Connections - Evaporator Suits “Victaulic” type Coupling & Pipe Assembly
Water Inlet / Outlet mm / (in) 50 (2 ”) 50 (2 ”) 65 (2 1/2 ”) 65 (2 1/2 ”) 65 (2 1/2 ”)
Connections - Condenser Suits “Victaulic” type Coupling & Pipe Assembly
Water Inlet / Outlet mm / (in) 65 (2 1/2 ”) 65 (2 1/2 ”) 65 (2 1/2 ”) 80 (3 ”) 80 (3 ”)
Water System - Evaporator
Min. System Water Volume (3) l 376 511 653 792 733
Max. System Press Bar 10 10 10 10 10
Water System - Condenser
Min. System Water Volume (3) l 471 637 814 985 907
Max. System Press Bar 10 10 10 10 10
(1) Nominal Cooling Duties based on 12/7°C evaporator water and 30/35°C condensing water, where output is the chilled water
duty and input is the compressor input power.
All performance data is supplied in accordance with BS EN 14511-1:2013
(2) EER is the Cooling Duty  compressor input power.
(3) For minimum system volume refer to Minimum System Water Volume Calculations .
