General Specification
MECHANICAL DATA
UWC200 UWC225 UWC240 UWC250 UWC270
Duty – Cooling
Cooling Only (1) kW 242.9 273.7 262.2 306.3 305.9
Nominal Input (1) kW 56.9 64.5 62.9 72.0 72.2
EER (2) 4.3 4.2 4.17 4.3 4.2
Capacity Steps % 0-25-50-75-100 0-20-30-50-70-80-100 0-17-33-50-67-83-100 0-25-50-75-100 0-19-33-52-67-86-100
Dimensions - H x L x W mm 1850 x 2000 x 760 1900 x 3200 x 900 1850 x 2000 x 760 1900 x 3200 x 900
Weight
Machine - D kg 1450 1525 1420 1590 1750
- DQ kg 1490 1565 1490 1630 1820
- DSQ kg 1520 1595 1510 1670 1840
Operating - D kg 1490 1580 1490 1650 1830
- DQ kg 1530 1620 1560 1690 1900
- DSQ kg 1560 1650 1580 1730 1920
Construction - Material / Colour Plain Galvanised Steel Base with Galvanised Sheet Steel, Epoxy Baked Powder Paint
Superstructure – Light Grey (RAL 7035)
Evaporator Brazed Plate
Insulation Class 0
Quantity 1 1 1 1 1
Water Volume l 14.6 22.1 22.5 24.8 27.0
Total Max. Water Flow l/s 16.8 19.0 18.1 21.3 21.1
Condenser Brazed Plate
Insulation Class 0
Quantity 1 1 2 1 2
Water Volume Circuit 1 l 26.6 31.1 23.9 35.6 23.9
Water Volume Circuit 2 l N/A N/A 23.9 N/A 32.9
Total Max. Water Flow l/s 19.8 22.5 18.1 25.2 21.1
Compressor Tandem Scroll - Hermetic Trio Scroll –
Hermetic
Tandem Scroll -
Hermetic
Trio Scroll –
Hermetic
Quantity 4 4 6 4 6
Oil Charge Volume (Total) l 4 x 4.7 6.3 + 4.7 + 6.3 + 4.7 6 x 3.4 4 x 6.3 4.7+4.7+4.7+3.4+3.4+3.4
Oil Type Polyol Ester
Refrigeration Dual Circuit
Refrigerant Control Electronic Expansion Valve
Refrigerant Precharged R407C
Charge (Total) Kg 15.0 + 15.0 18.6 + 18.6 17.6 + 17.6 20.8 + 20.8 23.2 + 18.7
Connections - Evaporator Suits “Victaulic” type Coupling & Pipe Assembly
Water Inlet / Outlet mm / (in) 65 (2 1/2 ”) 80 (3 ”) 80 (3 ”) 80 (3 ”) 80 (3 ”)
Connections - Condenser Suits “Victaulic” type Coupling & Pipe Assembly
Water Inlet / Outlet mm / (in) 80 (3 ”) 80 (3 ”) 80 (3 ”) 80 (3 ”) 80 (3 ”)
Water System - Evaporator
Min. System Water Volume (3) l 1044 941 763 1317 995
Max. System Press Bar 10 10 10 10 10
Water System – Condenser 1
Min. System Water Volume (3) l 1289 1163 927 1626 1213
Max. System Press Bar 10 10 10 10 10
Water System – Condenser 2
Min. System Water Volume (3) L N/A N/A 927 N/A 944
Max. System Press Bar N/A N/A 10 N/A 10
(1) Nominal Cooling Duties based on 12/7°C evaporator water and 30/35°C condensing water, where output is the chilled water
duty and input is the compressor input power.
All performance data is supplied in accordance with BS EN 14511-1:2013
(2) EER is the Cooling Duty  compressor input power.
(3) For minimum system volume refer to Minimum System Water Volume Calculations .
