Flow direction is reversed when used with Cylinder Actuator Failed
BODY PrESSUrE-TEMPErATUrE rATINgS:
Temperature
(F)
150
FLg
Steel
300
NPT, SWE,
or FLg Steel
150
FLg
St Steel
300
NPT, SWE,
or
FLg St Steel
+32° To 100°F
285
740
275
720
150°
272
710
255
670
175°
266
695
245
645
200°
260
680
235
620
225°
252
673
230
605
250°
245
667
225
590
275°
237
661
220
575
300°
230
655
215
560
325°
222
650
210
548
350°
215
645
205
537
375°
207
640
200
526
400°
200
635
195
515
450°
185
620
182
497
500°
170
605
170
480
550°
155
587
155
465
600°
140
570
140
450
650°
125
550
125
440
700°
110
530
110
435
750°
95
505
95
425
800°
80
410
80
420
Body Pressure — Temperature Ratings conform to ANSI based on body/
flange rating and body material. As the fluid temperature increases, the
maximum allowable internal pressure decreases. Verify maximum pressures
and temperatures prior to selecting body material and body/flange rating.
NOTE: Approaching limits for
continuous use will reduce trim
life. For continuous use, stay
within half of rated maximum.
NOTE ON BEARINGS: PEEK
Bearings should not be used
for temperatures above
450ºF or flowing differential
pressure above 300 PSIG.
TrIM MATErIALS
FLOWINg
DIFFErENTIAL
PrESSUrE LIMIT
316 Stainless Steel
100 PSID
TFE
100 PSID
PEEK
100 PSID
400 Stainless Steel
200 PSID
Alloy 6
300 PSID
ShUT-OFF (ALLOWABLE SEAT LEAkAgE) CLASSES
Leakage
Class
Maximum Seat Leakage
Test
Fluid
Test
Pressure
relative
Seat
Tightness
Class II
0.5% of rated CV
Water 45 to 60 PSI
1
Class III
0.1% of rated CV
Water 45 to 60 PSI
5
Class IV** 0.01% of rated CV
Water 45 to 60 PSI
50
Class V
0.0005 ml /min/inch
of trim size/ ∆P(PSI)
Water Max Operating ∆P 300,000
Class VI** Class VI about 0.9 ml/min * Air
50 PSI
600,000
* Leakage rate varies by valve size, Refer to the ANSI/FCI Standard
70.2.
**Class IV and V are the ONLY leakage classes available within the
5800 Series.
Pressure ratings are PSIG
For applications below 32° consult factory
