Warren Controls 3800 Series E-BALL ROTARY CONTROL VALVES - Manual

This document covers the installation, operation and maintenance
of the Series 3800 E-Ball Rotary Control Valves presented in the
“Series 3800 Product Specification”. The 3800 Series Rotary Globe
Control Valve incorporates the time-tested and proven Segmented
Ball–Eccentric Geometry design (E-Ball), combining exceptionally
tight control and rangeability (100:1), with superior trim wear
characteristics inherent with the eccentric design. Available as
completely automated valve assemblies with the highest quality
actuators and accessories or as bare stem product ready for your
automation needs, the 3800 Series comes in a wide variety of
standard options for body/trim materials and construction builds, from Class IV to Class VI shut off. The ever-popular TTZ Ceramic
Trim is an off-the-shelf choice for erosive or corrosive fluids and a
vast array of custom alloys can be selected for custom construction,
engineered to your specific application needs. The 3800 can flow in
the forward direction, flow-to-open; or reverse direction, flow-to-
close. The 3800 is available in a thru-shaft or split-shaft configuration.
These features allow for maximum flexibility in matching benefits to
your application. The 3800 offers a large combination of preferred
piping positions and acceptable actuator orientations to provide
maximum flexibility in mounting the valve in the piping.
TABLE OF CONTENTS
Overview .............................................Cover
Valve Identification ...............................2-3
Information Present on Valves ..........4-5
Performance Characteristics .............6-7
Weights & Dimensions ...........................7
Installation ...............................................8-9
Actuator Removal ................................... 10
Maintenance ............................................ 11
Packing Adjustment .............................. 11
Parts / Overhaul ...................................... 12
Parts Kits ..............................................13-14
Drawings..............................................15-19
Series 38OO
E-BALL ROTARY CONTROL VALVES
3800 IOM
PRODUCT OVERVIEW
The instructions given herein cover generally the operation and
maintenance of subject equipment. Should any questions arise
which may not be answered specifically by these instructions,
they should be referred to Warren Controls Inc. for further detailed
information and technical assistance. This manual cannot possibly
cover every situation connected with the operation, adjustment,
inspection, test, overhaul and maintenance of the equipment
furnished. Every effort is made to prepare the text of this manual so that engineering and design data is transformed into the most
easily understood wording. Warren Controls Inc., in furnishing this
equipment and this manual, must presume that the operation and
maintenance personnel assigned thereto have sufficient technical
knowledge and experience to apply sound safety and operational
practices which may not be covered herein. In applications where
Warren Controls Inc. furnished equipment is to be integrated
with a process or other machinery, these instructions should be
gENERAL INFORMATION
3800_IOM_RevB_0413
