Move
Clockwise
Line Event will occur the object moves in a
clockwise direction that start around.
*) Please don’t use as a signal for video
recording start.
Move Conter-
Clockwise
Line Event will occur the object moves in a counter-
clockwise direction that start around.
*) Please don’t use as a signal for video
recording start.
Path Event
: Detect route between two zones. (Max.10 path detection is possible).
NOTE:
* Disabled zone can not be configured.
* In Simple mode is not supported.
* The result of path event detection can be inaccuracy.
Output Direction Setup
: same as zone output configuration.
Clear All
: All path combinations clear.
2) Env.Setup(Environment setup)
: Configurations for each PVA functions.
- Md Sens(MD Sensitivity) : Adjust motion sensitivity.(HW sensitivity)
- Loiter Time (min): Time for judge to loitering object.
- Abandon/Absent Setup
Sens(Sensitivity) : Adjust sensitivity of abandon/absent detection.
Det Time (min): Time for judge to absent/abandon area.
Rst Time (sed): Time for maintain event. After this, background will be update.
- Scn Chg Setup (Scene Change Setup)
Sens(Sensitivity) : Adjust sensitivity of scene change detection.
Chg Ratio: Adjust judgment ratio that changed from the stored background.
Det Time (sec)
: Time for judge scene changing.
Rst Time (sec): Time for maintain event. After this, background will be update.
Unfocus : Detection on/off of unfocused state/defocused state.
- Windy Setup (Windy Area Detection Setup)
: Not applied in Simple PVA mode
Sens(Sensitivity) : Adjust sensitivity of windy object detection.
Det Time (sec)
: Time for judge to windy object.
Rst Time (sec)
: Time for release to windy object that staying with no motion
3) Display Setup
: Configuration for information on screen.
NOTE:
* Priority: Abandon/Absent > Loiter > Moving Object > Windy
* Same priority: large object size order
Alarm : Represent alarm icon on right-up side by of screen.
Counter
: Represent counting on left-bottom. (Det Only: When an event occurs)
Zone Area
: Represent active zone.
Moving Object
: Represent moving object with white rectangle.
Loitering
: Represent loitering object with green rectangle.
Abandon/Absent
: Represent abandon/absent area with wine colored rectangle.
Windy Area
: Represent moving object with violet rectangle.
4) dTracking Setup : Configurations for digital Pan/Tilt/Zoom.
NOTE:
* Prority : Tracking priority : Zone > Loitering > Abandon/Absent > Obj.
* Maximum 4 objects can be represented.
* Same priority: Continuing detect. And Obj. > Size
