CE – Conformity
The switch complies with all requirements of EN 61 326 with regard to interference emission
and immunity for use in industrial areas. We recommend the use of shielded cables. Installation
electromagnetic interference.
DIMENSIONS
Inches (mm)
12
1/4 NPT Standard
27 mm Hex
1.06” 1.22”
(31.1 mm)
30°
1.60”
(40.6 mm)
1.38”
(35 mm)
3.59”
(91.3 mm)
M12x1
Upper Part
Rotates 330°
