NOSHOK 800 Series Electronic Indicating Pressure Transmitter/Switch User Manual
Page 12

11
- Hysteresis
1 to 100% o
• Status indication
LED
Analog output
• Signal
4 to 20 mA, 2-wire; 0 to 10 Vdc, 3-wire
• Load resistance
Current output: < 500
Ω, Voltage output: > 10 k Ω
• Hysteresis
0.3% o
0.2% of full scale for thin lm cell
Display
• Type
7-segment LED, red, 4 digits, character height 7.6 mm
• Digits
-999 ... 9999
• Accuracy
1% of full scale
Rep
0.5% of full scale ( BFSL
Temperature ranges
• Storage
-22…+176°F
• Media
-4…+176°F
• Ambient
-4…+176°F
• Thermal Effect
0.017 % of Full Scale/°F
Electrical connection
Round connector M 12x1; 4-pin
Protection class
IP 65
CE - symbol
Interference emission and interference immunity in
accordance with EN 61 326
Electrical protection classes
Pole reversal and overvoltage protection
Weight
0.66 lbs
11
f full scale
f full scale for ceramic cell,
eatability
