ADC 500L - Manual (Page 38)

Defining SNMP Parameters PRELIMINARY
30 Megabit Modem 500L Installation Manual
PR
EL
IM
IN
A
RY
4 Click Submit to accept the changes.
You can change the community string to a name you choose. The fields have
default names as shown in the screen on
page 29 and are case sensitive. If you
change the name, however, the community string name must match on both
the manager and agent to allow access to the SNMP function.
Ž
Public is the default Trap Community String which is an authentication string
for the trap receiver. You can change the name, using up to 19 characters.

Public is the default Get Community String which is an authentication string
that enables an NMS to get status from the modem agent. You can change
the name, using up to 19 characters.

Private is the default Set Community String which is an authentication string
for an NMS to set or change parameters on the modem agent. You can
change the name, using up to 19 characters.
