− 20 − KEW6305
KEW6305 How to switch screens/ save data
7-3. How to switch screens/ save data
● Screens and switching method
< e.g. Three-phase 4-wire “3P4W” >
Wiring system (“Setting 01”) Displayed at
Parameters to be displayed
Screen 1 Screen 2 Screen 3 Screen 4
* Single-phase 2-wire (1ch) 1P2W(1ch)
Top
Middle
Bottom
TIME
WP
WS
− − −
* Single-phase 2-wire (2ch)
* Single-phase 3-wire
* Three-phase 3-wire
* Three -phase 3-wire 3A
1P2W(2ch)
1P3W
3P3W
3P3W3A
Top
Middle
Bottom
TIME
WP
WS
TIME
WP1
WS1
TIME
WP2
WS2
−
* Single-phase 2-wire (3ch)
* Three -phase 4-wire
1P2W(3ch)
3P4W
Top
Middle
Bottom
TIME
WP
WS
TIME
WP1
WS1
TIME
WP2
WS2
TIME
WP3
WS3
● Saving data (Data will be saved automatically.)
Screen1 Screen2 Screen3 Screen4
Integration interval Energy
Elapsed time
Data saving
Start of integration
(Manual/ automatic operation)
Energy to be saved.
0
End of integration
(Manual/ automatic operation)
