Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
1 Dynamic
Variables
2 Configuration /
Test
3 Quit/Reset
4 HART Variables
1 Flow Units
2 Full Scale
3 Zero Value
4 Zero Calibration
Opt
5 Master TC
6 L.F.Cutoff
7 Meter Size Units
Opt
8 Meter Size
9 GK Value
10 Flow Direction
11 VOS Min/Max
Units
12 Min VOS
13 Max VOS
1 Test / Info
2 Installation
3 Service Menu
4
5
1
1
1 L.F.Cutoff
2 Cutoff on
Opt
3 Cutoff off Opt
1 Flow
2 Version
3 Display
4 Current Output I
5 Pulse Output P
6 Digital Input C
7 User Data
8 Logging
1 Converter Function
2 Temperature
Units Opt
3 Input 1 4mA Opt
4 Input 1 20mA Opt
5 Pressure Units Opt
6 Input 2 4mA Opt
7 Input 2 20mA Opt
8 K0 Opt
9 K1 Opt
10 K2 Opt
11 Density 15 Opt
12 Heat Flow Units Opt
13 Full Scale Opt
1 Display Flow
2 Function Totalizer
3 Display Totalizer
4 Volume Units
Opt
5 Energy Units Opt
6 VOS Units
7 Cyclic Display
8 Error Messages
9 Date
10 Analog Input
Opt
11 Signal Gain
12 Display Formats
1 Format Flow Loc
2 Format
Heat Flow Loc, Opt
3 Format Volume Loc
4 Format
Energy Loc, Opt
3
KROHNE UFC030 HA 45e70201 (2/5)
05/04
Designations:
Opt Optional, dependent on device
implementation / configuration
Rd Read-only
Loc Local HC275/FC375,
affects only HC275/FC375 views
UFC 030 HART Menu Tree HC275 / FC375
