Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
Configure
Compare
Clear Offline
-----------------------------------
Status/Conditions
Process Variables
Scan Device
-----------------------------------
Calibration Management
Diagnostics and Test
Calibrate
Reset
Paramter Protection
-----------------------------------
Rename
Unassign
Assign / Replace
-----------------------------------
Audit Trail
Record Manual Event
Drawings / Notes ...
Help ...
Designations:
Opt
Optional, dependent on device
implementation / configuration
Rd
Read-only
Loc
Local AMS, affects only AMS views
UFC 030 HART Menu Tree AMS
Measuring Path
• Path 1 active
...
• Weight 1
...
• Length 1
...
• Zero Value Path 1
• Time Window Start
• Time Window End
Plausibility Filter
• Error Limit
• Counter Decrement
• Counter Limit
Device
Device Info
• Manufacturer
Rd
• Model Number
Rd
• Serial Number
Rd
• µP1 HW No.
Rd
• µP2 SW No.
Rd
• FE HW No.
Rd
• DSP HW No.
Rd
• DSP SW No.
Rd
• Version
• Enable Reset
Simulation
• Simulation Mode
• Uncorrected Flow
• VOS
• Gain
• Analog Input 1
Opt
• Analog Input 2
Opt
HART
Revision Numbers
• Universal rev
Rd
• Fld dev rev
Rd
• Software rev
Rd
• Hardware rev
Rd
Preambles
• Num req preams
Rd
• Num resp preams
Rd
Identification
• Manufacturer
Rd
• Model
Rd
• Dev ID
Rd
• Poll Addr
• Tag
• Date
• Dev des
• Message
• Write Protect
Rd
Final asmbly num
Snsr s/n
Dynamic Variables Settings
• PV is
Rd
• SV is
• TV is
• 4V is
Available I/O
Opt
• SI Units
Opt
• Pulse Output
Opt
• Current Output
Opt
• Digital Input
Opt
• Analog IO module
Opt
• HART Interface
Opt, Rd
• FF Interface
Opt, Rd
• PA Interface
Opt, Rd
• MODIS Version
Opt, Rd
Test Current Output I
Test Pulse Output P
Opt
Test Analog Inputs
Opt
Zero Calibration
Opt
Calibrate Current O. I
Opt
Calibrate Analog Inp. 1
Opt
Calibrate Analog Inp. 2
Opt
Calibrate Path
Opt
Quit Errors
Reset Totalizers
Opt
Master Reset
Reset Conf. Changed Flag
Reset Menu Parameters
Opt
Reset Service Param.
Opt
Reset Calibration Par.
Opt
Reset All Parameters
Opt
Reset Factory Par.
Opt
Entry Code 1
Service Code
3
