Supplementary Installation and Operating Instructions UFC 030 HART
HC275, FC375, AMS, PDM
5 Process Device Manager (PDM)
5.1 Installation
If the UFC 030 Device Description is not already installed on the PDM System a so called Device Install is needed
(available as download from KROHNE ‘Download Centre’ on the internet or on floppy disk / CD-ROM from
KROHNE).
For installing the DD with the Device Install refer to the “PDM Manual” section 11.2:”Device Install / Integrating
Devices in SIMATIC PDM with 'Device Install'". Please read also the “readme.txt”, which is also contained in the
Device Install.
5.2 Operating
Refer to the UFC 030 Menu Tree PDM (Attachment C).
Due to PDM requirements and conventions the UFC 030 operation differs to some extent from operation with HC275
/ FC375 and via local keypad.
Due to limitations of the HC275 / FC375 which affect also PDM there are some peculiarities:
• The online help of each parameter is only a short form help. However it contains the function number as a
reference to the device’s local display and the “Installation and Operating Instructions” for a comprehensive
description.
• Some selection lists (e.g. for output functions) may contain items which are actually not valid for the device
concerned. However invalid settings are rejected when trying to send them to the device.
Parameter protection via passwords (Entry Code, Service Code) is the same as on local display. Please refer to the
online help for valid symbols according to device’s keypad.
